Single Row Black PCB Header Connector Through Hole 40 Pins PBT Plastic

Product Information:

1. Pitch:2.54mm(0.1'')

2. Products Name:PCB Header Connector/Female Header

3. Number of Row:Single

4. Current Rating:3.0 AMP

5. Contact Resistance:20mΩ Max

6. Withstand Voltage:500 V AC/DC

7. Insulation Resistance:1000mΩ Min

8. Operation Temperature:-40°C to +105°C

9. Contact Material: Phosphor Bronze

10. Contact Plating: Gold Flash

11. Insulator Material: PA6T+30% GF UL94V-0

12. Mounting Type:DIP/Through Hole

13. Termination: Solder

14. Color:Black

15. Solder Temperature:260℃ for 10 Seconds

What is a PCB Connector?

Printed Circuit Board connectors are connecting systems, which are used to transfer signals or power from one PCB to another, or to or from the PCB from another source in the equipment build. As PCBs are not hard-wired to each other and can be assembled later in a production process, providing an easy method of Design for Manufacture.

PCB Connector orientations

The term PCB Connector refers to a basic multipin connection system, typically in a rectangular layout. A mating pair of PCB Connectors will either be for board-to-board or cable-to-board (wire-to-board). The board-to-board layouts can give a range of PCB connection orientations, all based on 90 degrees increments: Parallel or mezzanine – both connectors are vertical orientation;90 Degree, Right Angle, Motherboard to Daughterboard – one connector is vertical, one horizontal;180 Degree, Coplanar, Edge-to-Edge – both connectors are horizontal orientation.

Other names for PCB Connectors

PCB Connectors are known as PCB Interconnect product. Specific terms are also used for the two sides of the connection. There are also some other names for PCB connectors: Male PCB Connectors usually referred to Pin Headers, as they are simply rows of pins, while Female PCB Connectors named as Sockets, Receptacles, or even (somewhat confusingly) Header Receptacles.
