    1*15P Screw Terminal Block Connector Pluggable Type 30-12AWG H18.2mm R/A With Screw

    Ask Lasest Price
    Brand Name : CNJWY
    Model Number : CPT25-01-508
    Certification : UL.CE
    Payment Terms : T/T, Western Union
    Supply Ability : 10000000
    Delivery Time : 1week
    • Product Details
    • Company Profile

    1*15P Screw Terminal Block Connector Pluggable Type 30-12AWG H18.2mm R/A With Screw

    Product Name: Pluggable Terminal Block


    1. Product features: switching high-frequency high voltage insulation life long seismic


    2. Product material: copper alloy, or copper alloy, electroplating nickel, or nickel alloy


    3. Application: mainly used in communications, lighting, security and etc.. And the application of industry pluggable terminal is the main pan, such as frequency conversion, riot, numerical control panel, access controller, sensor, PLC, instrumentation, power, servo drive, the common requirements of these applications for pluggable terminal industry are: insertion force should be smooth, contact resistance to be small, must be able to meet the certain life and fatigue, so higher requirements for the metal shrapnel material. This requires that product designers have certain experience in structure and material. For the fence type terminal applications: power supply, relay (especially double terminal), frequency

    converter, the elevator industry (less), air conditioning.


    TECHNICAL DATA:

    Center Space5.08mm
    Rated Current300V 18A
    Surge Voltage4000V
    Insulation BodyPA66 UL94, V-0
    Terminal BodyBrass
    PCB Diameter1.3mm
    Temperature-40℃~105℃
    Wire Range30-12AWG
